| AC forward Centrifugal fan YWFF160 |
Detailed produt description
| |
|
|
|
|
|
|
|
|
|
|
| Forward Centrifugal fan YWFF160 |
|
|
|
|
|
|
|
|
—Material:
- Housing: galvanized sheet steel
|
|
|
|
|
|
|
|
- Impeller: galvanized sheet steel
|
|
|
|
|
|
|
|
|
- Rotor: Coated in black plastic
|
|
|
|
|
|
|
|
|
| —Diameter of Impeller: 160mm |
|
|
|
|
|
|
|
|
| —Direction of rotation: Clockwise, seen on rotor |
|
|
|
|
|
|
| —Type of protection: IP54 |
|
|
|
|
|
|
|
|
| —Insulation class: B or F |
|
|
|
|
|
|
|
|
| —Mounting position: Shaft horizontal or rotor on bottom; rotor on top on request(Any) |
|
|
|
| —Condensate discharges: Rotor-side |
|
|
|
|
|
|
|
| —Mode of operation: Continuous operation (S1) |
|
|
|
|
|
|
| —Bearings: Maintenance- free ball bearings |
|
|
|
|
|
|
|
| —Motor protection: Design with thermal overload protector |
|
|
|
|
|
| —Cable exit: variable, lateral |
|
|
|
|
|
|
|
|
| —Product conforming to standard: CE Approval |
|
|
|
|
|
|
| —Approval: UL Approval, CCC Certificate |
|
|
|
|
|
|
|
| |
|
|
|
|
|
|
|
|
|
|
| performance parameters |
|
|
|
|
|
|
|
|
| Model |
Voltage V |
Frequency Hz |
Current A |
Input Power W |
Speed RPM |
Capacitor μF |
Netweight KG |
Noise dB(A) |
Max Air Flow m³/h |
Curve |
| YWF-F4E-160 |
230 |
50/60 |
0.34/0.40 |
70/90 |
1370/1550 |
3 |
5 |
58/62 |
370/440 |
2,4 |
| YWF-F2E-160 |
230 |
50/60 |
0.98/1.1 |
215/240 |
2300/2200 |
6 |
4,5 |
64 |
560/520 |
1,3 |
